The post Bladder Tank Foam Proportioning System appeared first on hdfire.

]]>
  • Vertical or Horizontal unit
  • Maximum working pressure: 175 psi (12.1 bar)
  • Optional supply: UL Listed Foam Bladder Tank for 230 psi (16 bar)
  • Construction: Carbon Steel or Stainless Steel
  • Internally and Externally coated
  • Tank made to ASME Code Section VIII Div I
  • Earth lug for electrical safety
  • Optional: Increased wall thickness for specific corrosion allowance
  • Capacity: 140 litres to 15000 litres (36 to 4000 gal)
  • UL Listed with AFFF, AR-AFFF, FP and AR-SFFF Foam Concentrates
  • Nylon reinforced Buna-n-rubber bladder
  • Proportioner pre-piped on to the Bladder Tank
  • Provided with thermal pressure relief valve
  • Bladder Tank filling kit provided as an option (needs to be specified in the requirement)
  • UL Listed, FM Approved, CE Mark (needs to be specified in the requirement)
  • ASME U Stamp available as an option (needs to be specified in the requirement)
  • Choice of Standard (Red RAL 3001) or Corrosion-Resistant Epoxy exterior coating

    • Advantages of Bladder Tanks

    • Requires only a pressurized water supply for operation, no other external power is needed
    • Pre-piped option for easy installation
    • Reversible water inlet direction: Water can be directed from either of the sides
    • Standard Unit comes with pressure gauges (UL & FM approved), control valve, thermal pressure relief valve, sight glass and fill & drain valves
    • All valve and accessories accompanied with identification name plates
    • Can be offered in flanged or grooved inlet/outlet connection
    • Foam Filling kit is offered for easy and seamless installation

    The post Bladder Tank Foam Proportioning System appeared first on hdfire.

    ]]>         Foam Bladder Tank with pre-assembled Deluge Valve https://www.hdfire.com/products-solutions/foam-proportioning-systems/bladder-tank-with-pre-assembled-deluge-valve/ Sat, 06 Jul 2024 11:36:10 +0000 https://www.hdfire.com/?post_type=product&p=20282 Vertical or Horizontal unit Maximum working pressure 12 Bar (175 PSI) Carbon Steel or Stainless Steel Construction Tank made to ASME Code Section VIII Div I ASME U Stamp available as an option Capacity up to 15,000 liters (4000 gal.) Compatible with all foam concentrates Proportioner & Deluge Valve pre-piped on to the tank UL

    The post Foam Bladder Tank with pre-assembled Deluge Valve appeared first on hdfire.

    ]]>
  • Vertical or Horizontal unit
  • Maximum working pressure 12 Bar (175 PSI)
  • Carbon Steel or Stainless Steel Construction
  • Tank made to ASME Code Section VIII Div I
  • ASME U Stamp available as an option
  • Capacity up to 15,000 liters (4000 gal.)
  • Compatible with all foam concentrates
  • Proportioner & Deluge Valve pre-piped on to the tank
  • UL Listed Bladder Tank, Proportioner and Deluge Valve

    • The post Foam Bladder Tank with pre-assembled Deluge Valve appeared first on hdfire.

    ]]>         Ratio Controller https://www.hdfire.com/products-solutions/foam-proportioning-systems/ratio-controller/ Sat, 06 Jul 2024 11:45:20 +0000 https://www.hdfire.com/?post_type=product&p=20285 Wafer Type or Flanged Connection 65, 80, 100, 150 & 200 mm size (2.5”, 3″, 4″, 6″ & 8″) with flow from 100 to 18500 lpm (26 to 4887 gpm) Used with Bladder Tank or Inline Balance Pressure Proportioner for variable flow Caters to 3% or 6% induction simply by changing orifice Service Pressure :

    The post Ratio Controller appeared first on hdfire.

    ]]>
  • Wafer Type or Flanged Connection
  • 65, 80, 100, 150 & 200 mm size (2.5”, 3″, 4″, 6″ & 8″) with flow from 100 to 18500 lpm (26 to 4887 gpm)
  • Used with Bladder Tank or Inline Balance Pressure Proportioner for variable flow
  • Caters to 3% or 6% induction simply by changing orifice
  • Service Pressure : Maximum 3 to 14 bar (44 to 200 psi)
  • UL Listed and FM Approved (Refer to product catalogue HD263 for details)

    • The post Ratio Controller appeared first on hdfire.

    ]]>         Foam Concentrate Control Valve https://www.hdfire.com/products-solutions/foam-proportioning-systems/foam-concentrate-control-valve/ Sat, 06 Jul 2024 11:48:10 +0000 https://www.hdfire.com/?post_type=product&p=20288 25, 40 and 50 mm (1”, 1½” & 2″ ) size Stainless steel material Hydraulically controlled valve Working pressure 2.1 to 12 Bar (30 to 175 psi) Suitable to be used with Foam Bladder Tank and Inline Balanced Pressure Proportioning System Model CV is provided with visual indicator and limit switch Model CV is FM

    The post Foam Concentrate Control Valve appeared first on hdfire.

    ]]>
  • 25, 40 and 50 mm (1”, 1½” & 2″ ) size
  • Stainless steel material
  • Hydraulically controlled valve
  • Working pressure 2.1 to 12 Bar (30 to 175 psi)
  • Suitable to be used with Foam Bladder Tank and Inline Balanced Pressure Proportioning System
  • Model CV is provided with visual indicator and limit switch
  • Model CV is FM Approved with Foam Bladder Tank Proportioning System

    • The post Foam Concentrate Control Valve appeared first on hdfire.

    ]]>         Inline Balanced Pressure Foam Proportioner https://www.hdfire.com/products-solutions/foam-proportioning-systems/inline-balanced-pressure-foam-proportioner/ Sat, 06 Jul 2024 11:53:01 +0000 https://www.hdfire.com/?post_type=product&p=20291 Bronze or Stainless steel material with Stainless Steel trims 65, 80, 100, 150 & 200 mm size (2½”, 3″, 4″, 6″ & 8″) with flow ranging from 180 to 17400 lpm Working pressure 2.8 to 14 bar (40 to 200 psi)

    The post Inline Balanced Pressure Foam Proportioner appeared first on hdfire.

    ]]>
  • Bronze or Stainless steel material with Stainless Steel trims
  • 65, 80, 100, 150 & 200 mm size (2½”, 3″, 4″, 6″ & 8″) with flow ranging from 180 to 17400 lpm
  • Working pressure 2.8 to 14 bar (40 to 200 psi)

    • The post Inline Balanced Pressure Foam Proportioner appeared first on hdfire.

    ]]>         Inline Foam Inductor https://www.hdfire.com/products-solutions/foam-proportioning-systems/inline-foam-inductor/ Sat, 06 Jul 2024 11:57:58 +0000 https://www.hdfire.com/?post_type=product&p=20295 Bronze or Stainless steel construction 65, 80, 100 & 150 mm (2.5″, 3″, 4″ & 6″) size with fix flow of 75 to 3500 lpm Working pressure 6.4 to 12 bar (93 to 175 psi) Maximum back pressure as 65% Each unit is calibrated and factory tested for flow, induction rate at maximum back pressure

    The post Inline Foam Inductor appeared first on hdfire.

    ]]>
  • Bronze or Stainless steel construction
  • 65, 80, 100 & 150 mm (2.5″, 3″, 4″ & 6″) size with fix flow of 75 to 3500 lpm
  • Working pressure 6.4 to 12 bar (93 to 175 psi)
  • Maximum back pressure as 65%
  • Each unit is calibrated and factory tested for flow, induction rate at maximum back pressure

    • The post Inline Foam Inductor appeared first on hdfire.

    ]]>         Portable Inline Foam Inductor https://www.hdfire.com/products-solutions/foam-proportioning-systems/portable-inline-foam-inductor/ Sat, 06 Jul 2024 12:02:16 +0000 https://www.hdfire.com/?post_type=product&p=20298 Stainless Steel or Bronze construction Can be fitted on mobile foam units 65 mm (2.5”) size with fixed flow of 225 or 450 lpm Inlet pressure: Calibrated at 7 or 12 kg/cm2 Yellow Finish FM Approved with HD AFFF3% and AR-AFFF 3X3% FM Foam Concentrate UL Listed with HD AR-SFFF F3 Foam Concentrate Compact and

    The post Portable Inline Foam Inductor appeared first on hdfire.

    ]]>
  • Stainless Steel or Bronze construction
  • Can be fitted on mobile foam units
  • 65 mm (2.5”) size with fixed flow of 225 or 450 lpm
  • Inlet pressure: Calibrated at 7 or 12 kg/cm2
  • Yellow Finish
  • FM Approved with HD AFFF3% and AR-AFFF 3X3% FM Foam Concentrate
  • UL Listed with HD AR-SFFF F3 Foam Concentrate
  • Compact and portable design for ease of use

    • The post Portable Inline Foam Inductor appeared first on hdfire.

    ]]>         Atmospheric Foam Concentrate Storage Tank https://www.hdfire.com/products-solutions/foam-proportioning-systems/atmospheric-foam-concentrate-storage-tank/ Sat, 06 Jul 2024 12:10:12 +0000 https://www.hdfire.com/?post_type=product&p=20302 Horizontal unit design for efficient installation and foam storage Made up to 15000 liter (4000 Gal) storage capacity Stainless Steel 304/316 material Comes with ladder, sight glass and air vent Expansion dome of 2% tank capacity Flat end or dome end Yellow, Custom or Red RAL 3001 epoxy painted Tank can be custom made with

    The post Atmospheric Foam Concentrate Storage Tank appeared first on hdfire.

    ]]>
  • Horizontal unit design for efficient installation and foam storage
  • Made up to 15000 liter (4000 Gal) storage capacity
  • Stainless Steel 304/316 material
  • Comes with ladder, sight glass and air vent
  • Expansion dome of 2% tank capacity
  • Flat end or dome end
  • Yellow, Custom or Red RAL 3001 epoxy painted
  • Tank can be custom made with inline inductor mounted on the tank
  • Ideal for industrial firefighting systems, oil & gas, and chemical storage facilities

    • The post Atmospheric Foam Concentrate Storage Tank appeared first on hdfire.

    ]]>         Foam Concentrate By Pass Valve https://www.hdfire.com/products-solutions/foam-proportioning-systems/foam-concentrate-by-pass-valve/ Sat, 06 Jul 2024 12:13:08 +0000 https://www.hdfire.com/?post_type=product&p=20305 Bronze or Stainless steel construction 40 & 50 mm (1.5″ & 2″ ) size Female BSP end connection Suitable for use in Balance Pressure Foam Proportioning System

    The post Foam Concentrate By Pass Valve appeared first on hdfire.

    ]]>
  • Bronze or Stainless steel construction
  • 40 & 50 mm (1.5″ & 2″ ) size
  • Female BSP end connection
  • Suitable for use in Balance Pressure Foam Proportioning System

    • The post Foam Concentrate By Pass Valve appeared first on hdfire.

    ]]>         Skid Mounted Balance Pressure Foam Proportioning System https://www.hdfire.com/products-solutions/foam-proportioning-systems/skid-mounted-balance-pressure-foam-proportioning-system/ Sat, 06 Jul 2024 12:20:18 +0000 https://www.hdfire.com/?post_type=product&p=20308 Compact skid mounted unit with Foam Concentrate Pump, Ratio Controller, By-pass Valve, Relief Valve, Electricals etc Offers wide range of flow from 270 to 18500 lpm (71 to 4887 gpm) without any need for manual adjustment Ready to hook up to the system

    The post Skid Mounted Balance Pressure Foam Proportioning System appeared first on hdfire.

    ]]>
  • Compact skid mounted unit with Foam Concentrate Pump, Ratio Controller, By-pass Valve, Relief Valve, Electricals etc
  • Offers wide range of flow from 270 to 18500 lpm (71 to 4887 gpm) without any need for manual adjustment
  • Ready to hook up to the system

    • The post Skid Mounted Balance Pressure Foam Proportioning System appeared first on hdfire.

    ]]>
